Altronix PD16WCB
Altronix PD16WCB
In stock!
The Altronix PD16WCB is a sub-assembly power distribution module that takes a single AC or DC input and splits it into sixteen PTC-protected outputs, each auto-resettable and rated at 2.5A, for feeding multiple locks, strikes, or cameras from one supervised source. Its compact form factor is built to mount directly inside an Altronix power supply enclosure rather than as a standalone box, and a master power LED gives a quick local status check.
Key Features
- Sixteen individually PTC-protected outputs from one input
- Compact sub-assembly for easy mounting inside Altronix enclosures
- Master power LED indicator
Technical Specifications
- Input/Output: 12VDC, 24VDC, or 24VAC (up to 28V operation)
- Total supply current: 10A maximum, main fuse rated 10A/32V
- Individual output PTCs rated at 2.5A
