Ansul 73022

R-102 Double Tank Nitrogen Cartridge with Integrated Pressure Gauge

The Ansul 73022 is a high-pressure nitrogen propellant system engineered specifically to deliver the precise gas volume required for synchronized discharge of dual 3.0-gallon agent tanks in commercial kitchen fire suppression applications. Unlike CO2, nitrogen provides consistent pressure performance across temperature variations.

Key Features

• Integrated 0-4,000 PSI pressure gauge for system monitoring
• High-purity dry nitrogen for stable, temperature-independent performance
• Designed for synchronized two-tank discharge events
• Regulated pressure step-down to consistent 110 PSI operational pressure
• OEM component for Ansul R-102 kitchen fire suppression systems

Technical Specifications

• Tank pressure: Approximately 2,092 PSI
• Regulated discharge pressure: 110 PSI (7.6 bar)
• Pressure gauge range: 0-4,000 PSI
• Configuration: Double tank nitrogen cartridge
• Applications: Single, double, and multiple-tank R-102 systems
• Maintenance: Rechargeable by authorized Ansul service providers; typical 12-year service life

Certifications

• DOT/TC (Department of Transportation/Transport Canada) compliant
• Approved for pressurized gas cylinders in North America
• UL listed for R-102 fire suppression systems
