Apollo MR-201/T

The Apollo MR-201/T is a multi-voltage control relay in the MR-200 series providing DPDT (Double Pole Double Throw) 10-ampere contacts with operation from 24VDC, 24VAC, 120VAC, or 230VAC input signals. The relay features a red LED coil energization indicator and track-mounted installation for integration into fire alarm, HVAC, temperature control, and building automation panels.

Key Features

• Multi-voltage relay: 24VDC, 24VAC, 120VAC, or 230VAC operation
• DPDT contact configuration with 10-amp switching capacity
• Red LED indicates when relay coil is energized
• Track-mounted design for standard cabinet installation
• Rated for 10,000,000 mechanical operations
• Snap-apart modules support 4 or 8-position assemblies
• UL recognized control unit accessory

Technical Specifications

• Contact Configuration: DPDT (Double Pole Double Throw)
• Contact Rating: 10 amperes resistive
• Input Voltage: 24VDC, 24VAC, 120VAC, or 230VAC
• Voltage Range: 18–35 VDC/VAC, 120 or 230VAC
• LED Indicator: Red, energized state
• Mounting: Track mounted on DIN rail
• Mechanical Life: 10,000,000 operations rated
• Applications: Fire alarm, HVAC, temperature, security, lighting, building automation

Certifications

• UL Listed control relay
• UL recognized Control Unit Accessory
• Compatible with Apollo fire alarm systems
