Eaton Wheelock E90-24MCC-FR

Eaton Wheelock E90-24MCC-FR Ceiling-Mount Speaker Strobe (Red, FIRE Lettering, 15/30/75/95 cd)

The Eaton Wheelock E90-24MCC-FR is a red, ceiling-mounted speaker strobe designed for indoor fire alarm and emergency communication systems. Part of the E90 Series, it combines clear voice messaging with synchronized visual alerts, ensuring effective occupant notification.

Key Features

• Multi-Candela Xenon Strobe: Features field-selectable candela settings of 15, 30, 75, and 95 cd, providing flexibility to meet various room sizes and lighting conditions.

• Dual Voltage Operation: Compatible with both 25 and 70 VRMS audio systems, offering versatility in system design.

• Field-Selectable Power Taps: Supports power taps ranging from 1/8 to 2 watts, allowing customization based on application requirements.

• High-Fidelity Audio Output: Delivers clear and intelligible voice messages and tone signaling across a frequency range of 400 to 4000 Hz.

• Low Profile Design: Incorporates a speaker mounting plate with a snap-on grille cover, eliminating visible mounting screws for a clean appearance.

• Easy Installation: Designed for flush mounting to a standard 4-inch square backbox with an extension ring; includes IN/OUT screw terminals for quick wiring using #12 to #18 AWG wires.

• Synchronization Capability: Compatible with Wheelock’s DSM Sync Modules, Power Supplies, and SAFEPATH products, ensuring synchronized strobe flashes across devices.

• Regulatory Compliance: Meets UL 1971, UL 1480, UL 1638, CAN/ULC-S526, CAN/ULC-S541 standards, and complies with NFPA 72 and ADA requirements.

• Operating Temperature Range: Functions reliably in temperatures from 32°F to 120°F (0°C to 49°C) with a maximum humidity of 85%.
