Eaton Wheelock E90-24MCC-FW

Eaton Wheelock E90-24MCC-FW - Speaker Strobe

Key Features

• Ceiling-mounted speaker strobe combining audible and visual signaling
• White housing with FIRE lettering and clear lens
• 4-inch speaker with high intelligibility for voice evacuation
• Xenon strobe with field-selectable candela: 15, 30, 75, 95 cd
• Dual voltage: 25/70V compatibility for flexible system integration
• Power taps: 1/8 to 2 watts selectable
• Low-profile design with snap-on grille cover

Technical Specifications

• Voltage: 25/70V RMS (dual voltage selectable)
• Power Taps: 1/8 to 2 watts
• Candela Settings: 15, 30, 75, 95 cd
• Speaker Size: 4 inches
• Frequency Range: 400-4000 Hz
• Dimensions: 7.26"H × 7.26"W × 2.7"D
• Weight: 1.894 lb
• Mounting: Ceiling mount
• Operating Temperature: 0°C to 49°C (33.8°F to 120.2°F)
• Maximum Humidity: 93%

Certifications & Standards

• UL Standard 1971 (Signaling Devices)
• UL Standard 1480 (Speaker Appliances)
• UL Standard 1638
• CAN/ULC-S526 (Canada)
• CAN/ULC-S541 (Canada)
• NFPA 72 compliant
• ADA compliant
