Eaton Wheelock ET-1010-R
Speaker Surf Vandl Resis Red
Eaton Wheelock ET-1010-R Vandal-Resistant Speaker (Red)
The Eaton Wheelock ET-1010-R is a rugged, high-performance speaker designed for voice announcements and tone signaling in both indoor and outdoor environments. Featuring a vandal-resistant die-cast grille and sealed back construction, it ensures durability and reliable operation in demanding conditions.
Key Features
-
Vandal-Resistant Construction: Equipped with a die-cast grille and sealed back to withstand tampering and harsh environments.
-
Dual Voltage Compatibility: Supports both 25 and 70 VRMS audio systems, providing flexibility in system design.
-
Field-Selectable Power Taps: Offers seven tap settings ranging from 1/8 to 8 watts, allowing customization of sound output levels.
-
High Efficiency: Delivers clear voice and tone signals across a frequency range of 400 to 4000 Hz, with sound output up to 94 dBA at 10 feet.
-
Versatile Mounting Options: Designed for wall or ceiling mounting, suitable for various installation requirements.
-
Outdoor Rated: UL Listed for outdoor use when installed with the Wheelock WBB weatherproof backbox.
-
Compliance: Meets UL 1480, UL 1971, CSFM, MEA, BFP, and FCC Part 15 standards, ensuring adherence to safety and performance regulations.
-
Operating Temperature Range: Functions reliably in temperatures from -40°F to 150°F (-40°C to 66°C).
-
Dimensions: Measures 4.3” x 4.3” x 1.9” and weighs approximately 3 lbs.
