Eaton Wheelock MT4-115-WH-VFR

Eaton Wheelock MT4-115-WH-VFR - Multitone Horn Strobe

Key Features

• Wall-mounted multitone horn strobe with 115VAC operation
• White housing with fire alarm visibility
• 8 field-selectable alarm tones: Horn, Bell, March Time Horn, Code-3 Tone, Code-3 Horn, Slow Whoop, Siren, and Hi/Lo
• Xenon strobe with clear lens for high visibility
• Two output sound levels: Standard and High dBA
• Dip switch configuration for easy tone selection
• Indoor/Outdoor rated for flexible installation

Technical Specifications

• Voltage: 120 VAC
• Sound Level: 99 dBA (Standard), +5 dBA on High setting
• Tone Options: 8 field-selectable tones via dip switch
• Mounting: Surface or flush mount capability
• Dimensions: 4.06"H × 4.06"W × 0.76"D
• Housing: White UV stabilized plastic
• Operating Temperature: –40°F to 150°F (–40°C to 66°C)
• Strobe Type: Xenon with clear lens

Certifications & Standards

• CSFM (California State Fire Marshal)
• BFP (Chicago)
• FM (Factory Mutual)
• UL (Underwriters Laboratories)
• MEA (New York City)
• ADA compliant
