Eaton Wheelock ET70WP-24177C-FR
Speaker-Strobe Red Weatherproof Ceil 8W 177Cd
Eaton Wheelock ET70WP-24177C-FR Weatherproof Speaker Strobe (Red, Ceiling Mount, FIRE Lettering)
The Eaton Wheelock ET70WP-24177C-FR is a red, ceiling-mounted weatherproof speaker strobe featuring “FIRE” lettering. Designed for outdoor or harsh indoor environments, it provides reliable audible and visual signaling for fire alarm and emergency communication systems.
Key Features:
-
Weatherproof Design: Engineered for outdoor use with a temperature range of –40°F to 150°F (–40°C to 66°C), ensuring durability in extreme conditions.
-
High-Intensity Strobe: Features a fixed candela rating of 177 cd, delivering effective visual alerts in various settings.
-
Dual Voltage Operation: Compatible with both 25 and 70 VRMS audio systems, offering versatility in system design.
-
Field-Selectable Power Taps: Supports power taps ranging from 1/8 to 8 watts, allowing customization based on application requirements.
-
High-Fidelity Audio Output: Delivers clear and intelligible voice messages and tone signaling across a frequency range of 400 to 4000 Hz.
-
Easy Installation: Designed for surface mounting with the included IOB backbox; includes IN/OUT screw terminals for quick wiring using #12 to #18 AWG wires.
-
Synchronization Capability: Compatible with Wheelock’s DSM Sync Modules and power supplies, ensuring synchronized strobe flashes and horn tones across devices.
-
Compliance: Meets UL 1971, UL 1480, ULC, CSFM, and FM standards, ensuring adherence to safety and performance requirements.
