Eaton Wheelock LFHSHW3

Eaton Wheelock LFHSHW3 - Low Frequency Horn Strobe

Key Features

• 520 Hz low frequency sounder meeting NFPA sleeping room requirements
• 177 candela LED strobe output with 20ms pulse duration compliance
• Dual lettering: FIRE identification for emergency response
• 2W wall-mounted design with compact footprint (2" × 4.7" × 6.3")
• Industry-leading low current draw with high-efficiency LEDs

Technical Specifications

• Frequency: 520 Hz low frequency horn tone
• Visual Output: 177 candela
• Voltage: 24V DC operation
• Dimensions: 2" × 4.7" × 6.3"
• Weight: 1.18 lbs
• Housing: White textured UV stabilized plastic, 94V-0 rated

Certifications

• UL Standard 1480
• UL Standard 1971
• NFPA 72 2016 compliant (20ms light pulse)
• Note: Discontinued model - replaced by ELFHSW
