Edwards 3-6/3S1GYR LED and Switch Module
The Edwards 3-6/3S1GYR is an EST3 Control Display module providing emergency user interface with intuitive LED and switch controls for fire alarm panel operation. This module features six groups of three switches with corresponding LEDs in green, yellow, and red.
Key Features:
• Configuration: Six groups of three switches with individual LEDs
• Color Options: Green, yellow, and red LED indicators for status and function differentiation
• Functions: Page and evacuation select with zone trouble functionality
• Installation: Mounts over local rail modules with ribbon cable power/driver connection
Technical Specifications:
• Operating Voltage: 24 VDC
• Current: Standby 2.0 mA plus 1.5 mA for each active LED
• Environmental: Operating temperature 32-120°F (0-49°C), humidity 0-93% RH non-condensing at 90°F
Certifications:
• UL and ULC Listed: Fire alarm control panel component
