Condition: New
Edwards 4-NET-TP
Edwards 4-NET-TP
Controller SFP Network TX/RX Twisted Pair
Regular price
$536.99
Sale price
$536.99
Regular price
Shipping calculated at checkout.
Out of stock; call for lead time
The Edwards 4-NET-TP is a small form factor pluggable (SFP) network transceiver for EST4 fire alarm control panels, providing twisted-pair (or Cat 5) network media between panels. It plugs directly into a slot on the 4-CPU, 4-ANNCPU, 4-CPUGRPH, or 4-NET-AD module, letting facilities extend their EST4 network across long cable runs while supporting a large, distributed system of addressable devices.
Key Features
- Plug-in SFP module mounts directly into 4-CPU, 4-ANNCPU, 4-CPUGRPH, or 4-NET-AD modules
- Supports twisted pair or Cat 5 network media for EST4 panel-to-panel networking
- Enables large, distributed EST4 networks spanning vast distances between panels
Technical Specifications
- Data rate: 2 Mbps shared TX/RX
- Current draw: 32 mA at 24 VDC (standby and alarm)
- Operating temperature: 32°F to 120°F (0°C to 49°C)
- Humidity: 0-93% noncondensing
- Weight: 0.2 lb (0.091 kg)
- Environmental rating: Indoor, dry location
Certifications
- UL and ULC Listed
- FM Approved
- CSFM Listed
