Edwards 6536-G5

Call-for-Assistance Signaling Appliance - Clear Lens

Key Features

• Call-for-assistance signaling for healthcare and ADA applications
• Single-gang box installation for easy deployment
• Combined audible and visual output
• Clear lens for neutral appearance
• Ideal for nurse-call corridors and patient rooms
• Low-profile design suitable for public spaces
• 24V AC or 24V DC operation

Technical Specifications

• Operating voltage: 24V AC 50/60 Hz or 24V DC
• Audible output: 82 dBA at 10 feet
• Sound level at 24V AC: 175 mA current draw
• Sound level at 24V DC: 125 mA current draw
• Strobe output: 50 cd on-axis
• Mounting: Single gang 2" x 4" box
• Color: Neutral white finish

Certifications

• Not UL 464 or UL 1971 listed
• Suitable for healthcare facilities and ADA-accessible restrooms
• For NFPA 72 fire alarm use, specify UL-listed Genesis or 757 series
