Edwards 757-7A-SS70
Edwards 757-7A-SS70
Only 9 left!
The Edwards 757-7A-SS70 is a stainless steel speaker-strobe combining audible notification with synchronized LED strobe output, rated for 70-volt emergency notification systems. The 8-inch cone speaker with sealed back construction delivers high-quality audible evacuation signals and alarm tones, while the integrated 15/75 candela strobe provides visual notification to the hearing impaired across medium-to-large coverage areas.
Key Features
- Integrated speaker-strobe combining 70V audio with 15/75cd synchronized LED strobe
- Stainless steel housing for corrosion resistance in wet or harsh environments
- 8-inch cone speaker with sealed back construction for superior sound quality
- DC blocking capacitor for electrical supervision of audio distribution circuits
- Field-selectable wattage taps (1/4W to 2W) for installation flexibility
- Synchronized strobe operation on compatible NAC circuits
Technical Specifications
- Strobe Output: 15/75 Candela synchronized LED
- Voltage: 70V RMS rated at 90 ohms impedance
- Speaker: 8-inch cone with mylar facing and sealed back
- Sound Output: UL 1971 Listed per ADA standards
- Housing: Stainless steel with corrosion protection
- Wattage Taps: 1/4W, 1/2W, 1W, and 2W field-selectable
- Operating Temperature: 0° to 49°C
Certifications
- UL 1971 Listed speaker-strobe
- ADA compliant for hearing-impaired notification
