Edwards 757-7A-TW
Edwards 757-7A-TW
Only 8 left!
The Edwards 757-7A-TW is a temporal horn/strobe in white, rated 15/75cd, that delivers the standard NFPA 72 three-pulse temporal signal pattern from a synchronized 75cd strobe alongside the audible horn. Its housing is a durable, fire-retardant high-impact plastic with a slightly textured finish, flush-mounting to a standard 4-inch square or two-gang electrical box, and terminals accept up to #12 AWG wire for polarized connections on a constant-voltage (not pulsed) signal circuit.
Key Features
- Combination horn and synchronized strobe in one wall appliance
- NFPA 72-compliant temporal three-pulse pattern
- Rugged fire-retardant high-impact plastic housing
- Flush-mounts to 4" square or two-gang boxes
Technical Specifications
- Operating Voltage: 16-33VDC (constant, non-pulsed signal circuit)
- Strobe Output: 75cd (15/75cd rated)
- Wiring: Polarized, up to #12 AWG (2.5mm2)
- Mounting: 4" square or 2-gang box, flush
Certifications
- UL Listed fire alarm notification appliance, complies with NFPA 72 temporal signaling
