Edwards 965-7A-8SW

The Edwards 965-7A-8SW is an 8-inch square speaker-strobe designed for broadcast of emergency evacuation signals and high-quality voice communications. The large cone design provides exceptional audibility and intelligibility across comprehensive coverage areas, with synchronized LED strobe for visual notification of the hearing impaired on 70-volt emergency systems.

Key Features

• Large 8-inch speaker cone for superior frequency response and audibility
• Integrated 15/75 candela synchronized LED strobe output
• Sealed back construction for enhanced sound quality and efficiency
• DC blocking capacitor for audio circuit electrical supervision
• 70V RMS rated with field-selectable wattage taps (1/4W to 2W)
• Square 8-inch form factor for architectural blending
• Designed for life safety broadcast in hotels, malls, airports, hospitals

Technical Specifications

• Speaker Size: 8-inch diameter square cone with mylar facing
• Voltage Rating: 70V RMS @ 90 ohm impedance
• Strobe Output: 15/75 Candela synchronized LED
• Wattage Taps: 1/4W, 1/2W, 1W, 2W (field-selectable)
• Housing: Standard fire-retardant plastic with white finish
• Speaker Construction: Sealed back with cone diaphragm
• Operating Temperature: 0° to 49°C (32° to 120°F)

Certifications

• UL 1971 Listed speaker-strobe notification appliance
• ADA compliant for hearing-impaired notification
