Edwards EG1M-RM
Edwards EG1M-RM
Out of stock; call for lead time
The Edwards EG1M-RM is a remote-mount Genesis Signal Master synchronization module that adds two capabilities to a Genesis strobe or horn/strobe circuit over a single pair of wires: precision strobe synchronization and independent control of connected Genesis horns. It's a 1-gang remote-mount device rated at 3 amps, compatible with the full range of Genesis strobe candela variants as well as 2400 Series strobes, and is also used as an accessory synchronization module on EST CM2(N) control panels.
Key Features
- Synchronizes connected Genesis strobes to within UL requirements
- Provides independent horn control, traditional NAC silence or normally-closed contact, over the same two wires as the strobes
- Only one module required per notification circuit
Technical Specifications
- Rating: 3 amps (RM version)
- Operating Voltage: 16 to 33 VDC
- Wire Size: 18 to 12 AWG
- Mounting: 1-gang, remote mount
- Compatible Devices: Genesis and Enhanced Integrity strobes/horn-strobes, 2400 Series strobes
