Edwards G4HFRF-S7VMC
Edwards G4HFRF-S7VMC
Out of stock; call for lead time
The Edwards G4HFRF-S7VMC is a High Fidelity Genesis wall speaker-strobe in a red housing with a "FIRE" marking, built for sleeping-area applications where NFPA 72's 520 Hz low-frequency signaling requirement applies. Its speaker runs on a 70V circuit with field-selectable 1/4, 1/2, 1, or 2 watt output, and its clear-lensed strobe is field-selectable across 15, 30, 75, or 110 candela, both settings changed from a window on the unit without removing it from the wall.
Key Features
- High Fidelity 520 Hz audio circuit, meeting NFPA 72 sleeping-area requirements
- Field-selectable strobe output: 15, 30, 75, or 110 candela
- Field-selectable speaker wattage: 1/4, 1/2, 1, or 2 watts
- Red housing with "FIRE" marking, clear strobe lens
Technical Specifications
- Speaker Circuit: 70 Vrms
- Sound Output: 80.7 to 90.5 dBA depending on wattage setting (per UL 1480/ULC-S541)
- Mounting: Flush to a 4-inch square electrical box, 2-1/8 in deep
- Wire Size: 18 to 12 AWG
Certifications
- Meets ULC-S541 (2004), UL1638, UL1971, and UL1480 Fifth Edition requirements
