Edwards MPSR2-SHTW-GE

The Edwards MPSR2-SHTW-GE is a noncoded weatherproof manual pull station featuring heavy-duty die-cast construction for outdoor and harsh indoor environments. The double-action mechanism requires both a push bar and a pull lever to activate, reducing false alarms while maintaining accessibility in emergencies. Rated NEMA 4X for corrosive environments and Class I/II/III gas/vapor locations, this station includes a backbox for direct mounting and gold-plated snap-action contacts rated 10 amperes.

Key Features

• Double-action PUSH-PULL mechanism for false alarm prevention
• Die-cast metal construction with pre-painted corrosion protection
• Noncoded SPST normally open contact
• Hex-key reset access for secure operation
• NEMA 4X rating for all-weather outdoor use

Technical Specifications

• Contact: SPST normally open, 10A @ 24VDC
• Material: Die-cast aluminum with plated hardware
• Environmental rating: NEMA 4X (Class I/II/III groups E,F,G)
• Reset: Hex screwdriver required (vandalism resistant)
• Dimensions: 3.06" W x 4.75" H x 3.0" D
• Backbox: Included for outdoor mounting

Certifications

• UL 38 Listed manual fire alarm station
• FM Approved for life-safety applications
• NFPA 72 manual initiation device
