Condition: New
Edwards RLCD-R-2
Edwards RLCD-R-2
Annunciator LCD Red High-performance for IO Panels
Regular price
$630.99
Sale price
$630.99
Regular price
Shipping calculated at checkout.
Out of stock; call for lead time
The Edwards RLCD-R-2 is a red R-Series LCD remote annunciator for compatible Edwards EST fire alarm control panels, including EDGE-ML systems. It gives building staff a remote view of system status through a backlit display and front-panel indicators, without requiring additional programming beyond addressing.
Key Features
- Backlit 4-line by 20-character LCD display for event text and system status
- Front-panel status LEDs plus internal buzzer for audible alerts
- Acknowledge/silence and lamp test functions
- RS-485 communication, no programming required beyond addressing
Technical Specifications
- Power: 24 VDC continuous, 61 mA standby / 90 mA alarm
- Wiring: Class B/DCLB, redundant Class B/DCLB, or Class A/DCLA via RS-485 data riser
- Wire gauge: 18 to 14 AWG twisted pair; maximum run 4,000 ft
- Mounting: standard 4-inch square electrical box or listed R-Series enclosure
- Operating range: 32°F to 120°F, 0 to 93% relative humidity
