Edwards WG4WN-HVMC

The Edwards WG4WN-HVMC is an outdoor-rated Genesis wall/ceiling horn-strobe device in white with no marking. Featuring 24VDC operation and xenon strobe with clear lens, this compact notification appliance delivers 100.5/104.7 dB sound output at 1 meter, combining high-performance piezo sounder with multi-candela strobe capability for indoor and outdoor fire alarm applications.

Key Features

• Genesis WG4 series wall or ceiling mounting horn-strobe
• 24VDC powered with xenon strobe lamp and clear lens
• Sound output: 100.5/104.7 dB at 1 meter for effective audible notification
• Efficient piezo sounder technology
• Multi-candela strobe with UL 1971 synchronization precision timing
• Field-configurable for one of four candela intensity settings
• Sealed viewport display for installation candela verification
• Outdoor rated with optional gasket for recessed electrical box installation
• Operating temperature: -40°F to 151°F (-40°C to 66°C)

Technical Specifications

• Voltage: 24VDC
• Sound Output: 100.5/104.7 dB at 1 meter
• Sounder Type: Piezo efficient
• Strobe: Xenon lamp with clear lens, multi-candela output (field-configurable)
• Synchronization: UL 1971 compliant precision timing
• Temperature Range: -40°F to 151°F (-40°C to 66°C)
• Mounting: Wall or ceiling with optional backplane sealing gasket
• Color: White with no marking
• Application: Indoor and outdoor fire alarm environments including parking garages and process areas

Certifications

• UL 1971 Listed fire alarm horn-strobe
• UL 1638 compliance for strobe output specifications
• FM Approved for fire alarm applications
