Firelite CRF-300-RC
Firelite CRF-300-RC
RECON-Addrs Rly Module -Built-Intwo Formc Rlys
Regular price
$74.99
Sale price
$74.99
Regular price
Shipping calculated at checkout.
Only 1 left!
The Fire-Lite CRF-300-RC is an addressable relay control module providing two isolated sets of Form-C (DPDT) dry-contact outputs powered directly from the SLC loop. The module uses rotary switches for direct electronic addressing with automatic identification for streamlined installation.
Key Features
- Two isolated Form-C (DPDT) relay contact sets
- Powered directly from SLC loop (15-32 VDC)
- Rotary switch electronic addressing
- Automatic module type identification
- LED status indicators (green/red)
- No external power supply required
Technical Specifications
- Operating Voltage: 15-32 VDC from SLC
- Average Current: 230-255 µA (LED blink)
- Maximum Current: 6.5 mA (LED on)
- Relay Type: Form-C (DPDT) dry contacts
- Contact Rating: 3.0 A @ 30 VDC resistive, 0.9 A @ 125 VAC
- Operating Temperature: 32-120°F
- Humidity: 10-93% RH non-condensing
Certifications
- UL Listed relay module
- Fire-Lite addressable system compatible
- NFPA 72 compliant
