Gamewell FCI AMM-4SF

The Gamewell FCI AMM-4SF is an addressable monitor module for analog addressable fire alarm systems. It provides monitoring of conventional 2-wire smoke detectors or any alarm initiating device with normally-open dry contacts, including heat detectors, manual stations, water flow switches, and 4-wire smoke detectors. The module supports a single Style D, Class A circuit or alternatively Style B, Class B configuration with an end-of-line resistor.

Key Features

• Single Style D, Class A initiating device circuit with group address capability
• Supports conventional 2-wire smoke detector groups and various contact-type devices
• Line resistance support up to 25 ohms
• Mounts in 4-inch square backbox, 2-1/8 inches deep
• Up to 159 monitor modules per signaling line circuit on compatible panels

Technical Specifications

• Circuit Configuration: Single Style D, Class A initiating circuit (converts to Style B, Class B with end-of-line resistor)
• Maximum Line Resistance: 25 ohms
• Compatible Panels: Gamewell-FCI analog addressable fire alarm control panels
• Signaling Protocol: Uses enhanced communication protocol for increased sensor-to-panel communication speed
• Mounting: 4-inch square backbox

Certifications

• UL Listed addressable monitor module
• NFPA 72 compliant
