Gamewell FCI HPF-PS6B

The Gamewell FCI HPF-PS6B is a 6-amp remote power supply and notification appliance circuit (NAC) expander for 24VDC fire alarm systems. It delivers regulated 24V power on multiple outputs, supports synchronized strobe operation, and includes integrated battery charging for fire alarm monitoring and building notification systems.

Key Features

• 6 amp 24VDC power supply with NAC expander functionality
• Five power-limited outputs configurable as Class B or Class A with ZNAC-PS converter
• Each circuit supplies up to 3A with independent protection
• Synchronized strobe support: Temporal 3/4 coding and UL-listed sync for System Sensor, Wheelock, Gentex, AMSECO
• Integrated battery charger: accommodates two 7-18 Ah batteries or up to 33 Ah external
• Built-in LED indicators, dual Form C trouble relays, wide EOL supervision 2-27 kΩ

Technical Specifications

• Primary Power: 120VAC ±10%, 50/60 Hz, 5.0A maximum
• Output: Five 24VDC, 3A each (total 6A with share management)
• Battery Support: Internal (2x 7-18 Ah) or external (33 Ah)
• Dimensions: 20.0"H x 14.5"W x 3.5"D
• Enclosure: Black cabinet with internal DIN rail

Certifications

• UL 864 Listed fire alarm control unit
• NFPA 72 compliant
