Gamewell FCI PID-95P
Gamewell FCI PID-95P
Only 1 left!
The Gamewell-FCI PID-95P is an addressable point identification device that interfaces non-powered, normally-open dry-contact initiating devices - such as waterflow switches or manual stations - onto a two-wire analog signaling line circuit (SLC), giving each contact device its own identifiable address. It supervises a single Style B circuit, is field-programmable via DIP switches, and includes a status LED for local alarm annunciation.
Key Features
- Interfaces conventional dry-contact devices onto an addressable SLC loop
- Field-programmable address via DIP switches, with priority interrupt support
- Status LED provides local visual indication of activation
- Designed for concealed mounting in a double-gang or 4" square electrical backbox
Technical Specifications
- Standby current: 0.0005A to 0.0008A
- Alarm current: 0.0015A
- Compatibility: Gamewell-FCI 600 Series and ILI95-E3 Series fire alarm control panels
- Dimensions: 4" x 4.688" mounting plate
Certifications
- UL Listed addressable monitor/interface device for Gamewell-FCI analog SLC systems
