Gamewell FCI SLP-RETROFIT

The Gamewell FCI SLP-RETROFIT is an upgrade kit for retrofitting existing IF602 and 7100 B-SLIM cabinet installations with the Smart Loop Panel (SLP) system, featuring a 4.3-inch color touchscreen display. The kit includes a new mounting plate and red cabinet door, enabling operators to upgrade to modern addressable fire alarm control panel functionality while reusing existing cabinet infrastructure.

Key Features

• Smart Loop Panel retrofit kit for IF602 and 7100 B-SLIM cabinets
• 4.3-inch high-resolution color touchscreen display
• Removable display usable as a remote annunciator
• Supports System Sensor and Apollo intelligent devices
• One signaling loop (expandable to two loops)
• Class A or Class B wiring support (Style 4, 6, or 7)
• Four Class B or two Class A NAC circuits with strobe synchronization
• Network system support (up to 122 nodes)
• Includes mounting plate and red cabinet door

Technical Specifications

• Display: 4.3-inch color touchscreen (removable)
• Power Supply: 7.0 amp @ 120VAC or 240VAC
• Signaling Loops: 1 (expandable to 2)
• System Sensor devices: Up to 318 per SLC
• Apollo devices: Up to 126 per SLC (expandable to 252)
• NAC Circuits: 4 Class B or 2 Class A
• Strobe Synchronization: System Sensor, Cooper-Wheelock, or Gentex
• Network Nodes: Up to 122 nodes with E3 Series, 64 with 7100 Series
• Retrofit for: IF602 and 7100 B-SLIM cabinet installations

Certifications

• UL 864 9th Edition listed
• IBC Seismic certified
