Gentex AVSM-W
Gentex AVSM-W
Only 3 left!
The Gentex AVSM-W is a white synchronization control module that converts separate horn and strobe circuit inputs into a single 2-wire output to the field, reducing copper and conduit needs on installations using Gentex Commander series appliances. It multiplexes the panel's horn and strobe signals so the audible portion can be silenced while the strobes keep flashing at the code-required 1 Hz rate, and its "Daisy Chain" ports let multiple AVSM modules link together to synchronize notification zones across a building.
Key Features
- Converts 4-wire input into a 2-wire output, cutting copper and conduit fill
- Independent horn silence while strobes continue flashing
- Daisy Chain synchronization ports to link multiple AVSM modules across zones
- Automatically generates the ANSI S3.41 Temporal 3 pattern for horns
Technical Specifications
- Voltage Range: 8-33 VDC (compatible with 12V and 24V systems)
- Current Rating: 3.0A continuous, 5.0A surge
- Mounting: 4" x 4" x 2-1/8" deep backbox
Certifications
- UL 464 and UL 1971 Listed
