Kidde GSA-CRR

The Kidde GSA-CRR is a polarity reversal relay module that reverses 24VDC riser polarity to activate all sounder bases on a fire alarm loop. When integrated with a Kidde Signature Series loop controller, this module provides a Form C relay contact rated for 2 Amps @ 24Vdc pilot duty, enabling coordinated alarm signaling across distributed audio alerting devices.

Key Features

• Polarity reversal relay module for sounder base activation
• Reverses 24VDC riser polarity to trigger all bases simultaneously
• Form C relay contact for make/break control logic
• Compatible with Kidde Signature Series fire alarm loops
• Mounts to standard North American 2.5-inch or 4-inch boxes
• Requires electrical power to operate

Technical Specifications

• Function: Polarity reversal relay for sounder base coordination
• Relay Contact: Form C, 2 Amps @ 24Vdc (pilot duty)
• Secondary Contacts: 0.5A @ 120Vac, 0.25A @ 220Vac (non-UL)
• Load Limitation: Not rated for capacitive loads
• Control Voltage: 24VDC riser from fire alarm loop
• Mounting: 2.5" (64mm) or 4" square boxes with 1-gang covers
• Power Requirement: Requires electrical power for operation

Certifications

• UL Listed control relay module
• Compatible with Kidde Signature Series fire alarm systems
