Kidde GSA-MCT2

The Kidde GSA-MCT2 is a dual input plug-in module for the UIO (Universal Input/Output) motherboard system, providing intelligent analog addressable device capability for monitoring two independent normally-open alarm, supervisory, or monitor dry contact circuits. This module enables detailed device-level supervision for HVAC shutdown, elevator recall, fire door monitoring, and auxiliary system control.

Key Features

• Dual input intelligent addressable device for two independent circuits
• UIO plug-in format for modular system flexibility
• Accepts Class B normally-open alarm/supervisory/monitor contacts
• Supports personality code configuration (codes 1-4 compatible)
• Ideal for HVAC shutdown, elevator recall, and fire door monitoring
• Terminal block wiring on UIO motherboard
• Supports two- or six-module UIO motherboard configurations

Technical Specifications

• Device Type: Intelligent analog addressable dual input module
• Input Type: Class B normally-open dry contact circuits
• Applications: Alarm, Supervisory, or Monitor device types
• Configuration: Addressable personality codes (codes 1-4)
• Mounting: UIO plug-in module format
• Wiring: Terminal block connections on motherboard
• Motherboard Options: Two-module or six-module UIO platforms

Certifications

• UL/ULC Listed addressable input module
• Compatible with Kidde Signature Series fire alarm systems
