Condition: New
Mircom MIX-M500DMAP
Mircom MIX-M500DMAP
Module Monitor Intel Dual Input Req Two Conse
Regular price
$193.99
Sale price
$193.99
Regular price
Shipping calculated at checkout.
Only 5 left!
The Mircom MIX-M500DMAP is an intelligent dual-input monitor module that provides two independent, 2-wire initiating device circuits at two separate, consecutive SLC addresses from a single module. It's built for intelligent addressable fire alarm systems that need to bring in multiple conventional-style input circuits without using a full address point per circuit.
Key Features
- Two independent 2-wire initiating device circuits (IDC) at two consecutive addresses
- Monitors normally open contact fire alarm and supervisory devices, or normally open or normally closed security devices
- Connects to the SLC of a compatible Mircom fire alarm control panel
- Mounts directly to a standard 4-inch square electrical box
Technical Specifications
- Wiring: Class B / Style B only
- Addressing capacity: up to 99 modules in CLIP mode, up to 159 modules in Advanced Protocol (AP) mode
- Minimum electrical box depth: 2-1/8"
