Mircom TX3-CX-1NP
Mircom TX3-CX-1NP
In stock!
The Mircom TX3-CX-1NP is a single-door, Power-over-Ethernet access control controller from the Mircom TX3 Series, designed for discreet mounting inside an electrical box near the protected door. Unlike the standard TX3-CX-1, this "No Proximity" variant omits an onboard card reader, instead connecting to an external Wiegand reader for 125 kHz or 13.56 MHz credentials — useful where a specific reader form factor or frequency is required.
Key Features
- Single-door access control, powered via PoE or 12V/24-48V DC
- Connects to external Wiegand card readers (125 kHz or 13.56 MHz)
- Operates standalone or networked via RS-485/Ethernet
- Supports peer-to-peer communication for functions like anti-passback
- Two onboard relays and four supervised inputs
Technical Specifications
- User capacity: up to 124,000 users
- Offline event storage: up to 5,000 events
- Power input: PoE or 12V/24-48V DC
- Communication: RS-485 or Ethernet networking
Certifications
- Designed for use in UL Listed access control system installations
