Notifier ACM-48A
Notifier ACM-48A
In stock!
The Notifier ACM-48A is an addressable annunciator control module for Notifier ONYX Series and compatible fire alarm systems, featuring 48 color-programmable LED indicators and 48 momentary touch-pad switches. The module displays alarm and trouble conditions with individual red/green/yellow status indication per zone, integrated audio feedback, and remote monitoring capability over serial connection up to 6,000 feet from the control panel.
Key Features
- 48 programmable zone indicator LEDs (red/green/yellow)
- 48 momentary touch-pad switches with addressable control
- System Trouble LED and On-Line/Power LED for status indication
- Local piezo sounder with Silence/Acknowledge switch
- Expandable with AEM-48A expander module (96 points maximum)
- Serial interface communication, up to 6,000 feet from panel
- Compatible with Notifier ONYX series and legacy addressable panels
Technical Specifications
- LED Indicators: 48 color-programmable (red/green/yellow) active
- Switches: 48 momentary touch-pad
- Power Supply: 24VDC nominal (17-28VDC range)
- Standby Current: 0.016A
- Alarm Current: 0.070A (all LEDs on)
- Dimensions: 8.375"H x 4.375"W
- Serial Interface: Up to 6,000 feet distance
- Expansion: One AEM-48A module per ACM-48A (96 point maximum)
- Panel Compatibility: NFS-3030, NFS2-3030, AM2020/AFP1010, NFS-320, NFS2-640, NFS-640, AFP-100, AFP-200, AFP-300/AFP-400, NCA, NCA-2, INA
Certifications
- UL Listed for fire alarm annunciator systems
- Compatible with Notifier ONYX addressable fire alarm systems
