Notifier FDRM-1

Notifier FDRM-1 Dual Relay and Monitor Module

Key Features

• Multi output-input dual relay/monitor module
• Two individual relay control modules and two Class B monitor modules
• Form C switching for auxiliary device control
• Interface for contact-type devices
• Rotary decimal addressing (1-99 CLIP, 1-159 FlashScan)
• Integral LED indicators for status display

Technical Specifications

• Relay Outputs: Two individual relay control modules with Form C switching
• Monitor Inputs: Two Class B monitor modules for device interface
• Power: 15 to 32 VDC (SLC); 24 mA max (4 LEDs on)
• Operating Current: 1300 uA average
• Addressing: Rotary decimal (1-99 CLIP, 1-159 FlashScan)
• Operating Temperature: 32°F to 120°F (0°C to 49°C)
• Mounting: Standard 4.0″ square junction box (2.125″ deep)
• LED Indicators: Green during normal operation, red steady for alarm

Certifications

• UL/ULC Listed S635
• CSFM Listed 7300-0028:0219
• For Notifier Onyx and CLIP series FACPs
