Notifier XPM-8-RC

Notifier N-ANN-80 LCD Fire Annunciator

Key Features

• 80-character backlit LCD annunciator with remote mounting capability
• Mimics FACP display with system status information
• Control switches for acknowledge, silence, drill, and reset
• System status LEDs for all key indicators
• Local piezo sounder with resound capability
• Enclosure supervised for tamper protection
• Up to eight units per FACP ANN-BUS

Technical Specifications

• Display: 80-character backlit LCD (20 × 4 lines)
• Communication: Two-wire ANN-Bus serial interface
• Power: 18–28 VDC, 40 mA max at 24 VDC
• Remote Mounting: Up to 6,000 feet maximum distance from FACP
• Multiple Units: Up to eight N-ANN-80s per FACP ANN-BUS
• Status Indicators: AC Power, Alarm, Trouble, Supervisory, Alarm Silenced LEDs
• Supervision: Enclosure supervised for tamper detection
• Panel Compatibility: NOTIFIER FACPs with ANN-BUS (e.g., NFW-50)

Certifications

• UL Standard 864, 9th Edition
