Potter Electric Signal CHS-24W
Potter Electric Signal CHS-24W
Only 4 left!
The Potter Electric Signal CHS-24W is a 24VDC selectable horn/strobe combination notification appliance in a white ceiling-mount faceplate, built for fire alarm signaling in commercial occupancies. The strobe candela output and the horn's tone and cadence are both field-selectable, letting one device be configured to the coverage and sound-pressure requirements of a given space rather than stocking multiple fixed-output models.
Key Features
- Tamperproof field-selectable strobe output: 15, 30, 75, 95, 115, or 150 candela
- Horn switch-selectable between 2400Hz electronic tone or mechanical tone, continuous or temporal-3 pattern, and high/low dBA
- Super-Slide mounting bracket for easier installation and supervision testing, with Checkmate instant voltage verification
- Tamperproof re-entrant grille; faceplate available in white or red
Technical Specifications
- Operating voltage: 24VDC; operating temperature range 32-120 degrees F
- Strobe current: 74mA or less at 24VDC on the 15cd setting
- Wire range: 12-18 AWG; dimensions: 6 in. diameter x 2.6 in. depth
Certifications
- UL 464 Listed
