Potter Electric Signal PAD100-LFSB Addressable Low-Frequency Sounder Base

Key Features

• Addressable low-frequency sounder base for residential and commercial sleeping spaces
• Does not consume an address on the SLC loop
• Fully programmable to operate with any input device
• Complies with NFPA 72 low-frequency signal requirements (520 Hz)
• Compatible with all PAD100 detector heads for flexible installation
• Independent sounder module programmable as single station, zone, or all-call

Technical Specifications

• External Power Voltage: 16-33 VDC
• External Power Standby Current: 4.1 mA
• External Power Active Current: 33 VDC - 86.7 mA, 24 VDC - 96.5 mA, 16 VDC - 156.6 mA
• SLC Operating Voltage: 24 VDC
• SLC Standby Current: 200 µA
• Frequency: 520 Hz +/- 10% with square wave output

Certifications

• NFPA 72 Compliant (Sleeping Space Requirements)
• UL Listed
• Compatible with addressable fire alarm systems
