Potter Electric Signal PFC-4410-RC-R

Potter Electric Signal PFC-4410-RC Conventional Releasing Control Panel

Key Features

• Flexible multi-hazard releasing control panel for pre-action and deluge systems
• Microprocessor-based system with 24 standard programs
• 32-character alphanumeric LCD display with custom banner messages
• Four Class B initiating circuits, two Class B supervisory circuits, four Class B output circuits
• 40-event history buffer with programmable cross-zoning
• Menu-driven programming with walk test and automatic time-out

Technical Specifications

• Circuits: 4 Class B initiating, 2 Class B supervisory, 4 Class B output
• Discharge Capability: Continuous or timed
• Relays: Alarm, Trouble supervisory, and Flow relays
• Cabinet: Durable steel with removable door and key lock
• Finish Options: Red or white
• Optional: Flush mount trim ring available

Certifications

• NFPA 12 Compliant
• NFPA 12A Compliant
• NFPA 13 Compliant
• NFPA 15 Compliant
• NFPA 16 Compliant
• NFPA 72 Compliant
• UL 864 Listed
