Potter Electric Signal RMS-1T-WP-LP

Key Features

• Single-action addressable pull station for fire alarm systems
• Activated by simply pulling white "T" bar handle downward
• Non-coded addressable operation
• Compatible with Potter IPA and AFC/ARC addressable control panels
• Supports Class A, Class B, and Class X SLC wiring styles
• DIP switch addressing with no programming tools required
• ADA requirements compliant
• Simple reset procedure

Technical Specifications

• Operating Voltage: 24.0 VDC Maximum
• SLC Standby Current: 200µA Maximum
• SLC Alarm Current: 200µA
• Dimensions: 4.75"H x 3.25"W x 1.75"D
• Weight: 1.22 lbs
• Operating Temperature: 32°F to 120°F
• Humidity: 0-93% (non-condensing)
• Installation: Single gang box or surface mount with P32-BB/P32-DBB

Certifications

• UL 38 Listed
• ADA Compliant
• PAD protocol compatible
