Siemens (Pyro) ZIC-4A
Siemens (Pyro) ZIC-4A
Board 13 NAC Zones-Coded Or Non-Coded Sync
Regular price
$1,324.99
Sale price
$1,324.99
Regular price
Shipping calculated at checkout.
Core Charge $150
Eligible for credit if core is returned within 30 days of order
A core charge is a fee you pay when buying a part, that will be returned to you when you send the old part you’re replacing back. In other words, it’s a monetary incentive to get your old part so that we can recondition and continue to offer this part to future customers.
Out of stock; call for lead time
Key Features
- Four independently programmable output circuits
- Configurable as Class A (Style Z) or Class B (Style Y) circuits
- Compatible with audible/visual notification appliances and emergency audio systems
- On-board LEDs for system status and troubleshooting
- Ground fault detection via diagnostic LED
- Plugs into Model CC-5 or CC-2 card cage
- Advanced signal coding options for multiple protocols
Technical Specifications
- Number of Circuits: 4 output circuits
- Circuit Voltage: 24VDC
- Per-Circuit Amperage: 3A maximum per circuit
- Power Limit: 96 Watts per zone
- Total System Capacity: 12A maximum (single PSC-12 power supply)
- Installation: Fits one slot in CC-5 or CC-2 card cage via 96-pin DIN connectors
- Addressable via three-dial selector switches
- Wiring: Accommodates 12–18 AWG (single) or 16–18 AWG (dual)
- Output Configurations: Steady, strobe-synchronized, or zone-coded outputs
- Signal Coding: ANSI Temporal, March Time (30/60/120 PPM), Canadian Two-Stage, custom codes
Certifications
- UL Listed for fire alarm systems
- CE Marked
- NFPA 72 Compliant
