Siemens (Pyrotronics) 4100-6057

The Siemens 4100-6057 is a dual-core multimode fiber optic media card for Siemens Pyrotronics fire alarm control systems. This network interface module enables fiber optic communication links between multiple 4100 series control panels, creating a networked fire alarm system with point-to-point optical connectivity for noise-immune, secure alarm signal transmission.

Key Features

• Fiber optic network media module for 4100 series panels
• Dual multimode fiber optic cable support (transmit and receive)
• Noise-immune optical signal transmission
• Point-to-point networked panel connectivity
• Secure fiber optic communications for fire alarm systems
• Compatible with network interface modules and bi-directional couplers

Technical Specifications

• Media Type: Dual-core multimode fiber optic
• Fiber Core: 50 or 62.5 micron core with 125 micron cladding
• Wavelength: 850 nm (infrared)
• Cable Configuration: Two multimode fiber optic cables (transmit/receive)
• Operating Temperature: 32°F to 120°F (0°C to 49°C)
• Operating Humidity: Up to 93% RH, non-condensing at 90°F (32°C)
• Compatible Panels: Siemens 4100ESi and other 4100 series control panels

Certifications

• Siemens Pyrotronics approved network media module
• UL listed fire alarm system component
