Condition: New
Siemens (Pyro) DSC-W
Siemens (Pyro) DSC-W
Module Dual Sync Control White
Regular price
$142.99
Sale price
$142.99
Regular price
Shipping calculated at checkout.
Out of stock; call for lead time
Key Features
- Mini addressable interface module with dual isolators
- Direct mounting into single-gang electrical switchbox
- ISOtechnology dual isolation for NFPA 72 Class X survivability
- Supports polarity insensitive and isolator operation modes
- Compatible with X-series and H-series addressable devices
Technical Specifications
| Module Type | Mini Addressable Interface Module with Dual Isolators |
| Electrical Ratings | 32 Vdc average, 8 mA RMS |
| Loop Address | 1 address per module |
| Max Isolators Per Loop | Up to 252 isolation-ready devices |
| Mixed Mode Support | Max 30 non-isolated devices between isolated |
| Wire Size | 18 AWG minimum to 14 AWG maximum |
| Cable Length | Up to 200 feet (18 AWG to line) |
| Ground Fault Detection | At 25K ohms |
| Mounting | Direct into single-gang switchbox |
| Part Number | S54370-B4-A1 |
Certifications
- UL 864 Listed for addressable systems
- NFPA 72 Class X (Style 7) compliant
- Compatible with Desigo Fire Safety and Cerberus PRO
