Siemens (Pyro) FS-DB2-RC

The Siemens Pyro FS-DB2-RC is a low-profile detector base designed for surface mounting of intelligent addressable fire alarm detectors in conventional and addressable systems. The base includes a relay output for device signaling and supports both standard intelligent detectors and Siemens ASA-technology compatible sensors. The self-wiping contacts and screw-clamp terminals ensure reliable electrical connections, and the base is backward compatible with Siemens H-series intelligent detectors and detector-assigned FACPs.

Key Features

• Compatible with standard and ASA-technology intelligent detectors
• Relay output for detector-driven signaling
• Self-wiping contacts for improved reliability
• Screw-clamp terminals for straightforward wiring
• Backward compatible with H-series intelligent detectors
• Works with 252-point, 504-point, and FireFinder XLS fire systems
• Optional LK-11 detector locking kit available to prevent unauthorized removal

Technical Specifications

• Detector Compatibility: Standard and intelligent addressable detectors with ASA-technology support
• Contact Type: Self-wiping contacts with screw-clamp connections
• Relay Output: Included for signaling other devices
• System Compatibility: 252-point addressable, 504-point addressable, FireFinder XLS
• Mounting: Low-profile surface mount base
• Optional Accessory: Model LK-11 detector locking kit (50 locks included)

Certifications

• UL Listed for use in Siemens intelligent fire alarm systems
• Compliant with addressable system standards
