Silent Knight 5860TG

The Silent Knight 5860 is a 4x20 character LCD remote annunciator for intelligent addressable fire alarm control panels. The 80-character display provides real-time system status, alarm events, and device information in an easy-to-read format. Five status LEDs indicate alarm, supervisory, trouble, silence, and AC power conditions. The unit mounts flush or on the surface and communicates with the fire alarm panel via the RS-485 SBUS interface, supporting up to 15 remote annunciators per panel.

Key Features

• 4x20 LCD display with 80-character capacity for detailed event information
• Five status LEDs: Alarm, Supervisory, Trouble, Silence, AC Power
• Silicone mechanical controls with tactile and audible feedback
• RS-485 SBUS serial interface for panel communication
• Supports up to 15 remote annunciators per Silent Knight FACP
• Surface or flush mounting with optional trim ring (5860TG)
• Dipswitch configuration for ID assignment

Technical Specifications

• Power: 24 VDC standby 58 mA, alarm 68 mA
• Temperature Range: 0°C to 49°C (32°F to 120°F)
• Display: 4x20 LCD with 80-character backlit format
• Dimensions: 7.375 inches wide x 8.125 inches tall (bezel)
• Back box depth: adds 1.25 inches when surface or in-wall mounted
• Communication: RS-485 SBUS serial interface (requires JumpStart auto-programming at panel)
• Mounting: Surface, flush, single-gang, double-gang, or four-square electrical boxes

Certifications

• UL Listed for use with Silent Knight FACPs
• NFPA 72 compliant intelligent addressable annunciator
