Silent Knight IFP-2100ECS

Key Features

• Intelligent addressable fire alarm control panel with emergency communication system
• Red surface-mount cabinet finish
• Supports up to 2100 addressable points in any combination
• Integral emergency communication system with voice features
• Networking capability for multiple panel systems
• Supervised microphone with recordable emergency messages

Technical Specifications

• Panel Type: Intelligent Addressable FACP with ECS
• Device Capacity: 159 IDP detectors/modules per loop, 2100 total system points
• Signaling Loops: Multiple Signaling Line Circuits (SLCs)
• Power: 120V AC with battery backup
• Communication Features: Eight configurable Flexput circuits for NAC/auxiliary power
• Emergency Communication: Supervised microphone, 15 recordable one-minute messages, 520Hz tones, 25/70.7 Vrms speaker circuits
• Networking: Multi-panel support, up to 16 addressable amplifiers (2000W total), 128 speaker circuits
• Display: Backlit LCD with programming keypad
• Cabinet: Red surface-mount enclosure

Certifications

• UL Listed intelligent addressable FACP
• NFPA 72 compliant
• Silent Knight/Honeywell certification
• Emergency communication system certified
