Silent Knight PS-SATK-WP

The Silent Knight PS-SATK-WP is a weatherproof single-action manual pull station engineered for outdoor fire alarm installations where moisture and temperature extremes are concerns. This die-cast metal station features NEMA-rated weatherproofing with gasket and conduit connections, providing reliable SPST normally-open alarm initiation in harsh environmental conditions.

Key Features

• Weatherproof design with gasket and die-cast metal backbox tapped for 1/2" conduit
• Single-action pull operation for quick emergency response
• Die-cast metal construction with gold-plated contacts for corrosion resistance
• Surface mounting with terminal strip connections
• Meets ADA requirement of 5 lb. maximum pull force

Technical Specifications

• Contact Type: SPST normally open
• Contact Rating: 1 A @ 125 VAC or 30 VDC
• Activation: Single-action pull operation
• Reset: Hex key reset mechanism
• Mounting: Surface-mounted die-cast metal backbox with gasket
• Conduit: Tapped for 1/2-inch conduit connection
• Dimensions: 3-1/4 inches W × 2-1/4 inches D × 4-3/4 inches H
• Operating Temperature Range: -4°F to 140°F (-20°C to 60°C)

Certifications

• UL Listed for fire alarm service
• NEMA weatherproof rating for outdoor installation
• ADA compliant for accessibility and 5 lb. maximum pull force
