Simplex 4081-9003

The Simplex 4081-9003 is a 4.7 kΩ, 1/2 watt end-of-line resistor harness designed for current-limited monitoring applications in fire alarm systems. This component is connected at remote monitoring locations to provide wiring continuity supervision and ensures proper circuit function throughout addressable fire detection networks.

Key Features

• 4.7 kΩ resistance value specifically for current-limited monitoring circuits
• 1/2 watt power rating for reliable operation in fire alarm systems
• End-of-line resistor harness design for remote location installation
• Supports wiring continuity supervision for monitored circuits
• Compatible with Simplex addressable fire alarm control panels

Technical Specifications

• Resistance: 4.7 kΩ
• Power Rating: 1/2 W
• Part Number: 733-896
• Application: Current-limited circuit monitoring
• Circuit Supervision: Wiring continuity verification at remote points
• Compatible Systems: Simplex addressable fire alarm control panels

Certifications

• UL Listed for fire alarm system applications
