Space Age SSU-PAM-SD
Space Age SSU-PAM-SD
Module Relay PAM Series Multi-Volt 70A For
Regular price
$22.99
Sale price
$22.99
Regular price
Shipping calculated at checkout.
In stock!
The Space Age Electronics SSU-PAM-SD is an encapsulated relay module built for supervised 24VDC notification appliance circuit (NAC) applications. It switches Form C (SPDT) contacts rated at 7 amps, runs on an 18-32VDC polarity-sensitive, diode-protected input, and includes a second set of input wires so Class A circuit supervision can pass through the module rather than stopping at it.
Key Features
- Encapsulated relay for supervised 24VDC NAC applications
- Redundant input wiring supports Class A circuit supervision pass-through
- Built-in LED indicates when the relay coil is energized
- Polarity-sensitive, diode-protected input for safe wiring
Technical Specifications
- Contact configuration: Form C (SPDT), 7A rated
- Input voltage range: 18-32VDC
- Circuit supervision: Class A pass-through via redundant input
