System Sensor COSMO-2W
System Sensor COSMO-2W
In stock!
The System Sensor COSMO-2W is an i4 interface module that connects up to 12 i4-series (or compatible i3-series) smoke/CO multi-criteria detectors to a fire alarm control panel using only two to three conventional zones -- one smoke zone, one CO zone, and an optional trouble zone. Detectors signal in ANSI Temporal 3 for a smoke alarm and Temporal 4 for a CO alarm, and when any interconnected detector alarms, all of them sound together for full-area notification.
Key Features
- Connects up to 12 i4/compatible i3-series detectors to a conventional panel over 2-3 zones
- Distinct smoke and CO signals reported separately to the control panel
- Built-in 85 dB sounder and LED status indicators for normal, trouble, alarm, and end-of-life conditions
- Mounts to a 4-11/16 in. square back box with terminal blocks for field wiring
Technical Specifications
- Part No. COSMO-2W
- Capacity: Up to 12 compatible i4/i3-series smoke/CO detectors per module
- Signaling: ANSI Temporal 3 (smoke), Temporal 4 (CO)
- Mounting: 4-11/16 in. square back box
