Thermotech 302-AW-135

The Thermotech 302-AW-135 is an all-weather, rate-anticipation heat detector rated at 135 degrees F, built with a hermetically sealed housing and four wire leads so it can be installed indoors or outdoors without a special back box. Its rate-anticipation design holds the alarm trip point within roughly two to three degrees of the rated setpoint regardless of how fast or slowly the surrounding temperature rises, and the detector self-restores once conditions return to normal.

Key Features

• Rate-anticipation sensing holds the trip point within 2-3 degrees F of the rated setpoint at any rate of rise
• Hermetically sealed, moisture-proof and dust-proof housing for all-weather use
• Self-restoring, shock-resistant, and tamper-resistant construction
• Vertical mount, four-wire lead connection, no special back box required

Technical Specifications

• Fixed temperature rating: 135 degrees F (57 degrees C)
• Should not trip on momentary fluctuations under 30 degrees F/minute between 60-100 degrees F ambient
• Should not be installed in direct sunlight, hot air ducts, in front of heaters, or in paint booths

Certifications

• UL Listed and FM Approved heat detector
